    Mingtech Desktop Plug In Card Reader Ergonomics Design

    Ask Lasest Price
    Brand Name : Mingtech
    Model Number : MT3MT4D-MS-R313-DZ
    Certification : Contact PBOC3.0 L1,Contactless PBOC3.0 L1,Contact EMV L1,Contactless EMV L1,CE,FCC,RHOS
    Delivery Time : <15 days
    Supply Ability : 2500-3000 sets pers day
    Payment Terms : T/T, PayPal, Western Union, D/P, CommBank.
    • Product Details
    • Company Profile

    Mingtech Desktop Plug In Card Reader Ergonomics Design

    Desktop ergonomics design plug-in Card Reader


    Features

    • USB2.0 full speed
    • Smart card read/write
    • Standard ISO 7816

    • 3 SAM card sockets
    • 3 LED indicators
    • Support buzzer
    • OS support Windows XP/7/8/10,Linux/Android

    Specifications


    ProjectParameters Of Specifications
    Dimension
    Power Interface
    Power SourceUSB
    Supply VoltageDC 5V±5%
    Supply Current≦300mA
    Cable Length1.8m,Fixed
    Communication Interface
    ProtocolUSB HID
    SpeedUSB Full Speed(12Mbps)
    Contactless IC Card Interface
    StandardStandard ISO14443 Type A&B,S50/S70
    ProtocolISO14443 /1/2/3/4 T=CL,MIFARE
    Frequency13.56MHz±7kHz
    Speed106/212/424Kbps
    Operating Distance0~30mm
    Contact IC Card Interface
    standard

    Standard ISO7816 T=0/T=1 Smart Card;

    SLE4428/4442 Card;

    Speed9600~115200 bps
    Protectionshort-circuit protection and overcurrent protection
    EnduranceMinimum 100.000
    SAM
    Number of Slots3 Standard SIM-Sized Card Slots
    standardStandard ISO7816 protocol PSAM
    Others
    LEDThree LED,Red color LED for power status,Green color LED for card status and operate status
    BuzzerMonotone
    Device VisionSupport
    Device SNSupport
    Supporting SystemWindows XP/7/8/10,Linux/Android
    Working Environment
    Temperature0℃ ~ 50℃
    Humidity10% ~ 90%
    Technical Support
    DriverDo not need to install the driver
    APIWindows 32&64bit SDK
    Technical ServiceSupply SDK and Demo


    Certifications
    Contact PBOC3.0 L1,Contactless PBOC3.0 L1,Contact EMV L1,Contactless EMV L1,CE,FCC,RHOS



    Applications

    • E-government
    • Bank and payment
    • Electronic medical
    • cyber security
    • Access control
    • Public transit
